Product Details
2 independent MPPTs with an efficiency of up to 96%;
Maximum DC input current of 13.5A, suitable for mainstream photovoltaic modules in the market;
Maximum DC voltage of 60V, high safety;
Plug and play, easy installation;
Comprehensive intelligent monitoring and communication system;
IP 67 protection level, die-casting design;
25-year service life design, 10-year product warranty.
| Model | SPP200QH70S |
| Module Dimension (L×W×H) | 1270mm×900mm×2.5mm |
| Weight | 3.4 kg |
| Back material | Back Sheet(black) |
| Cell | 70(5×14)/Mono /166*83mm /φ223mm |
| Frame | no |
| Junction box(protection degree) | IP68 |
| Cable (length/cross-section area) | Customizable/ 4mm² |
| Connector | MC4 Compatible |
| Max-Power(Pm) | 200W |
| Power Tolerance | 0~+5W |
| Max-Power Voltage(Vm) | 19.8V |
| Max-Power Current(Im) | 10.11A |
| Open-Circuit Voltage(Voc) | 23.9V |
| Short-Circuit Current(Isc) | 10.65A |
| Effective Module Efficiency(ηm) | 20.40% |
